OD=80 mm x 180mm,
Voltage: 110V / 220V
Current 5A
Speed: 6000-24000 R/min
Power: 1500W (2HP)
Frequency:400 Hz
Water Cooling,
ER11 collect chuck ( for tool size 1/32″, 1/16″, 3/32″, 1/8″, 3/16″,7/32″, 1/4″)
–Tool not included
Grease Lubrication
Runout off: less than 0.005mm
Water cooling about 20-26 gal/hr
Weight: 8.5 ibs
Manual:
KL-1500 (3874 downloads)Use this VFD:
110V: 1.5KW VFD, Variable Frequency Drive (KL-VFD15), 110VAC input
220V: 1.5KW VFD Spindle Inverter (KL-VFD15), 220VAC input
You can use this water pump and tube for the spindle:
